Intel Optane Memory Tested As Boot Drive, Secondary and RAID 0

Jump To:

AS SSD Benchmark

AS-SSD (1.9.5986.35387) Benchmark:

We have been running the AS-SSD Benchmark app for over some time now and found that it gives a broad result set. The programmer has worked very hard on this software and continues to make updates often so if you use it, show him some love and send him a donation. There are now three tests that are found within the tool and we’ll show the results from all three of them.

Intel Optane Memory 32GB – Boot Drive:

Intel Optane Memory 32GB – Secondary:

Intel Optane Memory 32GB – Secondary RAID 0:

Benchmark Results: AS SSD showed the Intel Optane Memory 32GB drive had an overall score of 2,627 points with sequential read speeds of 1,239 MB/s and 276 MB/s write as the boot drive. Those scores improved with is as an empty secondary and then in RAID 0 we show up to an overall score of 4,765 with sequential read speeds of 2,473 MB/s and 551 MB/s write. The 4K read performance of ~140 MB/s as a boot drive and ~190 MB/s as a secondary was very impressive!
